Berlin
Berlin Ev. Kirche zum HeilsbronnenJörg Bente 2020 Neuorganisation und Neuintonation |
|||||
| I. Hauptwerk | II. Schwellwerk | ||||
| (C - g''') | (C - g''') | ||||
| Bordun | 16´ | Gedackt | 8´ | ||
| Prinzipal | 8´ | Flöte | 8´ | neu | |
| Rohrflöte | 8´ | Gambe | 8´ | ||
| Oktave | 4´ | Vox coelestis | 8´ | ||
| Spitzflöte | 4´ | Prinzipal | 4´ | ||
| Quinte | 2 2/3´ | neu | Blockflöte | 4´ | |
| Oktave | 2´ | Nasat | 2 2/3´ | aus HW | |
| Waldflöte | 2´ | aus SW | Octavin | 2´ | neu |
| Mixtur 4-5f. | 1 1/3´ | neu | Sesquialtera | 2f. | |
| Trompete | 8´ | Scharf 4f. | 1´ | neu | |
| Dulzian | 16´ | ||||
| Oboe | 8´ | neu | |||
| III. Brustwerk | Pedal | ||||
| (C - g''') | (C - f') | ||||
| Holzgedackt | 8´ | Prinzipal | 16´ | ||
| Rohrflöte | 4´ | Subbaß | 16´ | ||
| Rohrnasat | 2 2/3´ | Oktave | 8´ | ||
| Prinzipal | 2´ | Gedackt | 8´ | ||
| Oberton | 3f. | Oktave | 4´ | ||
| Flageolet | 1´ | Rohrpommer | 4´ | ||
| Cymbel 3f. | 1/2´ | Nachthorn | 2´ | ||
| Vox humana | 8´ | Rauschpfeife | 2f. | ||
| Mixtur | 3f. | neu | |||
| Posaune |
16´
|
||||
| Trompete |
8´
|
||||
| Schalmei |
4´
|
||||
| Tremulanten HW, SW, BW, Pedal | |||||
| Manualkoppeln I-II, III-II, III-I elektrisch | |||||
| Pedalkoppeln I-P, II-P, III-P mechanisch | |||||
| Zimbelstern | |||||
| Glockenspiel | |||||
| Winddrossel | neu | ||||
| Setzeranlage | neu | ||||
